CD 180 KMDL

ABOUT THIS PRODUCT

The Clark Drain CD 180 KMDL is a hinged ductile iron gully grating and frame (with locking screws) for use on estate roads, kerbside and highways. It is a straight bar, captive hinge, non-rock gully grating.

The CD 180 KMDL has internal dimensions of 430mm x 370mm and external dimensions of 570mm x 459mm x 100mm. It also has a clear opening of 430mm x 370mm for a 450mm diameter gully. Additionally, it has a waterway area of 994cm2.

Key Features:

  • Hinged gully grating and frame
  • It comes with locking screws
  • D400 Loading Classification
  • Straight bar, captive hinge, type S and non-rock
  • BS EN124-2:2015 and DMRB CD534 accreditations
  • Applications – highways, kerbside and estate roads

SPECIFICATIONS

Applications
Estate Roads, Highway, Kerbside
Accreditations
BS EN124-2:2015, DMRB CD534
Locking
Locking screws.
Loading
D400
Gratings
Straight Bar, Captive Hinge , Non-Rock
Material
Ductile Iron
Internal Dimensions
430 (L) x 370 (W)
External Dimensions
570 (L) x 459 (W) x 100 (D)
Clear Opening
430 x 370 (For 450 Diameter Gully)
Water Way Area
994cm2
